MEASURING PARAMETERS
Temperature: °C/°F
Measuring Range: +50°C to -50°C
Resolution: 0.06°C
Accuracy: ±0.1°C
TEMPERATURE MEASUREMENT
PT100, Class A
OPERATING RANGE
Ambient to 35°C
Max. R.H. 80%
MEASURING DEVICES
Cloud: Light-pulsed emission, I.R. spectrum; coaxial fiber optic system
Pour Point: PT100 Probe; mechanical arm adjusts the position of the test jar
COOLING SYSTEM
Integrated CFC-free motor compressors
Single stage (for temperatures up to -40°C / 1)
Double stage (for temperatures up to -50°C / 2)
Equipped with an automatic energy power save system
SAFETY DEVICES
Pressure controller for compressor
Thermo-switch for each cooling/heating jacket
Compressors equipped with internal overload devices
DIMENSIONS AND WEIGHT
66 x 60 x 80 cm (WxDxH), 20 kg (up to 4 heads available)
ELECTRICAL S…
