The XSZ-207 is a professional-grade biological compound microscope widely used in medical diagnostics, research, and educational laboratories. It is known for its versatility, offering configurations such as monocular, binocular, and trinocular heads for photography or digital imaging.
Key Specifications
Standard models typically include the following features:
Magnification: Often ranges from 40x to 1000x, though some specialized variants like the TICARE model reach up to 1600x.
Optics: Equipped with a quadruple nosepiece holding four achromatic objective lenses (4X, 10X, 40X, and 100X oil immersion).
Viewing Head: Most versions feature a Seidentopf-style head that is 360° rotatable and inclined at 30° or 45° for ergonomic use.
Stage: A double-layer mechanical stage (approx. 140x140mm) wi…
